Alpina

B12Total length (including towing bar) (mm)

B127738 - 11030

B15Total width (mm)

B152460

B5Mass in running order (kg)

B51652 - 2326

O1bMax. No. of berths

O1b4 - 9

The ultimate all-seasons caravan

The Alpina, with 'i-shaped' exterior, new graphics and contemporary and elegant interior, represents the ultimate caravan for all year round adventures. Inside there is more space and thanks to the unique concave cupboard design, more of a loft-style apartment feeling and the benefits of fully integrated Alde heating.

360° virtual tour



Interior comparison

Interior
Exterior
Day
Night
day
Modified Image


Textiles

Picture for illustration purposes only. Details may vary.

3 steps to your caravan

1. Layouts(8)

573 UP

Textiles

Brown Betty
Leather Fumo
Pommery

573 UP

Total length (including towing bar) (mm) B12

7738 B12

Total width (mm) B15

2460 B15

Mass in running order (kg) B5

1652 B5

Max. No. of berths O1b

4 O1b

Technical data

Dimensions and weights B

Awning perimeter dimensions (body/chassis) (cm)

1029/584

Body length (mm)

6271

Floor, wall and roof insulation thickness (mm)

38/29/29

Floor, wall and roof total thickness (mm)

47/33/32,8

Internal height (mm)

1950

Internal length (mm)

5652

Internal width (mm)

2310

Mass in running order (MRO) ( kg )

1652

Max loading weight (kg)

248

Max. technically permissible laden mass (MTPLM) / optional (kg)

1900

Total height (mm)

2600

Total length (including towing bar) (mm)

7738

Total width (mm)

2460

Chassis equipment C

AL-KO automatic adjustment

available with ATC

ATC Trailer Control

O

Alloy wheels

O

Chassis type

AL-KO

Coupling device AK

200 V AK 300

Coupling device AKS

O

Delta axle

X

Drawbar cover

X

Mud protection

O

Number of axles

1

Reinforced supporting legs

X

Shock absorbers

X

Spare wheel with holder

O

Steel wheels

X

Third wheel with the real tyre

O

Tyres size

215R14C108

Wheel box insulation

X

Wheel cover insert

X

Wheel trims

X

Body E

Adria windows - darker

X

Black-out roller blinds with flyscreen on all windows

X

Bodywork in polyester

X

Decorative roof luggage rack

X

Double gazed front windscreen

X

Entrance door 1-part with window

X

Exterior graphic design labels

X

Floor insulation Styrofoam

X

Flyscreen whole door

O

Front and rear wall lining in thermoformed ABS

X

Gas bottle locker

X

I-shape exterior design

X

Integrated aluminium tent profiles

X

Luggage door - left (light dimensions) (cm)

34x24

Luggage door - right (light dimensions) (cm)

27x105

Movable entrance step

X

Opening windows all

X

Panoramic window for caravans

X

Roof light Midi Heki 70x50 cm

X

Roof light Mini Heki S 40x40 cm

X

Side wall skirtings in aluminium

X

Side walls in polyester

X

Third break light

X

Interior equipment F

Bed coverlet

O

Bed with slatted frame and spring mattress

X

Blanket

O

Decorative curtains

X

Decorative pillows (4 pcs) 42x42 cm

O

Floor carpets

O

Foldable bunk bunk bed above parents bed

-

Headrest at sitting group

X

Kitchen window lining with LED lightening

X

Liftable headrest on parents bed

X

Overall sleeping places

4

Sitting group with Kaltschaum

X

Sleeping area, bunk beds (cm)

-

Sleeping area, central berths (cm)

-

Sleeping area, front berths (cm)

224x145/191

Sleeping area, rear berths (cm)

197x150

Table with wooden profile and telescopic leg

X

Kitchen equipment G

3-flame gas cooker with electric ignition, glass cover and stainless steel sink

X

Drainer

O

Extractor fan

X

Kitchen taps (cold & hot water)

X

Microwave oven

O

Microwave oven preinstallation

X

Oven

X

Refrigerator

167L

Sink cover / chopping board

O

Bathroom equipment H

Adria Ergobath type

A

Foldable washbasin

X

Separate shower faucet

X

Shower curtain

X

Shower tray

X

WC chemical, fixed, passive ventilated

X

WC chemical, turnable, passive ventilated

-

Wash-bowl

X

Washbasin in bedroom

-

Water installations I

Central waste water outlet

X

External inlet water connection to water facilities

X

Fresh water tank with external inlet (L)

50 L

Integrated waste water tank

O

Waste water tank (L)

O

Water level regulator 20l/50l

O

Electricity J

12V socket and TV aerial connector with coaxial cable

X

13-pin socket Jaeger

X

Additional spot lights in sitting area

X

Ambient LED lights below cupboards

X

Ambient LED lights on corner elements

X

Ambient LED lights over cupboards

X

Ambiental LED light at the bottom of kitchen unit

X

Awning LED light

X

Battery charger with battery box and external multifunctional outlet

X

Ceiling LED lights

X

Central lighting control panel

X

Control panel

X

LED rear exterior lights

X

Light in luggage compartment

X

Main fit switch

X

Main light switch at entrance door

X

Power sockets

X

Preinstallation for roof clima device

X

Signal D+ Preinstalations

X

Spot LED lights

X

USB switch

2x

Winter switch

X

Heating/air conditioning K

Ebeco foil for electrical floor heating system

-

Hot-water floor heating system Alde

X

Hot-water heating system Alde Compact 3000

X

Preinstallation for air condition

X

Smart control Alde

O

Transformer for electrical floor heating

-

Gas L

Gas bottle compartment 2 x 11 kg

X

Gas bottle holder

X

Gas regulation valve

X

Audio/video M

Bluetooth transmitter

O

Loudspeakers with preinstallation for bluetooth transmitter

X

Preinstallation for car radio with antenna and two loudspeakers

-

TV holder

X

613 UT

Textiles

Brown Betty
Leather Fumo
Pommery

613 UT

Total length (including towing bar) (mm) B12

8186 B12

Total width (mm) B15

2460 B15

Mass in running order (kg) B5

1700 B5

Max. No. of berths O1b

5 O1b

Technical data

Dimensions and weights B

Awning perimeter dimensions (body/chassis) (cm)

1078/633

Body length (mm)

6761

Ex-Works weight ( kg )

1610

Floor, wall and roof insulation thickness (mm)

38/29/29

Floor, wall and roof total thickness (mm)

47/33/32,8

Internal height (mm)

1950

Internal length (mm)

6142

Internal width (mm)

2310

Mass in running order (MRO) ( kg )

1700

Max loading weight (kg)

200

Max. technically permissible laden mass (MTPLM) / optional (kg)

1900

Total height (mm)

2600

Total length (including towing bar) (mm)

8186

Total width (mm)

2460

Chassis equipment C

AL-KO automatic adjustment

available with ATC

ATC Trailer Control

O

Alloy wheels

O

Chassis type

AL-KO

Coupling device AK

200 V AK 300

Coupling device AKS

O

Delta axle

X

Drawbar cover

X

Mud protection

O

Number of axles

1

Reinforced supporting legs

X

Shock absorbers

X

Spare wheel with holder

O

Steel wheels

X

Third wheel with the real tyre

O

Tyres size

215R14C108

Wheel box insulation

X

Wheel cover insert

X

Wheel trims

X

Body E

Adria windows - darker

X

Black-out roller blinds with flyscreen on all windows

X

Bodywork in polyester

X

Decorative roof luggage rack

X

Double gazed front windscreen

X

Entrance door 1-part with window

X

Exterior graphic design labels

X

Floor insulation Styrofoam

X

Flyscreen whole door

O

Front and rear wall lining in thermoformed ABS

X

Gas bottle locker

X

I-shape exterior design

X

Integrated aluminium tent profiles

X

Luggage door - left (light dimensions) (cm)

72x27

Luggage door - right (light dimensions) (cm)

27x105

Movable entrance step

X

Opening windows all

X

Panoramic window for caravans

X

Roof light Midi Heki 70x50 cm

X

Roof light Mini Heki S 40x40 cm

X

Side wall skirtings in aluminium

X

Side walls in polyester

X

Third break light

X

Interior equipment F

Bed coverlet

O

Bed with slatted frame and spring mattress

X

Blanket

O

Decorative curtains

X

Decorative pillows (4 pcs) 42x42 cm

O

Floor carpets

O

Foldable bunk bunk bed above parents bed

/

Headrest at sitting group

X

Kitchen window lining with LED lightening

X

Liftable headrest on parents bed

X

Overall sleeping places

5

Sitting group with Kaltschaum

X

Sleeping area, bunk beds (cm)

/

Sleeping area, central berths (cm)

217x110

Sleeping area, front berths (cm)

/

Sleeping area, rear berths (cm)

200x80, 193x80

Table with wooden profile and telescopic leg

X

Kitchen equipment G

3-flame gas cooker with electric ignition, glass cover and stainless steel sink

X

Drainer

O

Extractor fan

-

Kitchen taps (cold & hot water)

X

Microwave oven

O

Microwave oven preinstallation

X

Oven

X

Refrigerator

167 L

Sink cover / chopping board

O

Bathroom equipment H

Adria Ergobath type

C

Bathroom taps (washing & showering)

-

Foldable washbasin

-

Separate shower cabin with solid door

X

Separate shower faucet

X

Shower curtain

-

Shower tray

X

WC chemical, fixed, passive ventilated

-

WC chemical, turnable, passive ventilated

X

Wash-bowl

X

Washbasin in bedroom

-

Water installations I

Central waste water outlet

X

External inlet water connection to water facilities

X

Fresh water tank with external inlet (L)

50 L

Integrated waste water tank

O

Waste water tank (L)

O

Water level regulator 20l/50l

O

Electricity J

12V socket and TV aerial connector with coaxial cable

X

13-pin socket Jaeger

X

Additional spot lights in sitting area

X

Ambient LED lights below cupboards

X

Ambient LED lights on corner elements

X

Ambient LED lights over cupboards

X

Ambiental LED light at the bottom of kitchen unit

X

Awning LED light

X

Battery charger with battery box and external multifunctional outlet

X

Ceiling LED lights

X

Central lighting control panel

X

Control panel

X

LED rear exterior lights

X

Light in luggage compartment

X

Main fit switch

X

Main light switch at entrance door

X

Power sockets

X

Preinstallation for roof clima device

X

Signal D+ Preinstalations

X

Spot LED lights

X

USB switch

2x

Winter switch

X

Heating/air conditioning K

Hot-water floor heating system Alde

X

Hot-water heating system Alde Compact 3000

X

Preinstallation for air condition

X

Smart control Alde

O

Gas L

Gas bottle compartment 2 x 11 kg

X

Gas bottle holder

X

Gas regulation valve

X

Audio/video M

Bluetooth transmitter

O

Loudspeakers with preinstallation for bluetooth transmitter

X

TV holder

X

663 UK

Textiles

Brown Betty
Leather Fumo
Pommery

663 UK

Total length (including towing bar) (mm) B12

8650 B12

Total width (mm) B15

2460 B15

Mass in running order (kg) B5

1749 B5

Max. No. of berths O1b

8 O1b

Technical data

Dimensions and weights B

Awning perimeter dimensions (body/chassis) (cm)

1127/682

Body length (mm)

7232

Ex-Works weight ( kg )

1659

Floor, wall and roof insulation thickness (mm)

38/29/29

Floor, wall and roof total thickness (mm)

47/33/32,8

Internal height (mm)

1950

Internal length (mm)

6632

Internal width (mm)

2310

Mass in running order (MRO) ( kg )

1749

Max loading weight (kg)

251

Max. technically permissible laden mass (MTPLM) / optional (kg)

2000

Total height (mm)

2600

Total length (including towing bar) (mm)

8650

Total width (mm)

2460

Chassis equipment C

AL-KO automatic adjustment

available with ATC

ATC Trailer Control

O

Alloy wheels

O

Chassis type

AL-KO

Coupling device AK

200 V AK 300

Coupling device AKS

O

Delta axle

X

Drawbar cover

X

Mud protection

O

Number of axles

1

Reinforced supporting legs

X

Shock absorbers

X

Spare wheel with holder

O

Steel wheels

X

Third wheel with the real tyre

O

Tyres size

215R14C108

Wheel box insulation

X

Wheel cover insert

X

Wheel trims

X

Body E

Adria windows - darker

X

Black-out roller blinds with flyscreen on all windows

X

Bodywork in polyester

X

Decorative roof luggage rack

X

Double gazed front windscreen

X

Entrance door 1-part with window

X

Exterior graphic design labels

X

Floor insulation Styrofoam

X

Flyscreen whole door

O

Front and rear wall lining in thermoformed ABS

X

Gas bottle locker

X

I-shape exterior design

X

Integrated aluminium tent profiles

X

Luggage door - left (light dimensions) (cm)

34x22, 27x108

Luggage door - right (light dimensions) (cm)

34x24

Movable entrance step

X

Opening windows all

X

Panoramic window for caravans

X

Roof light Midi Heki 70x50 cm

X

Roof light Mini Heki S 40x40 cm

X

Side wall skirtings in aluminium

X

Side walls in polyester

X

Third break light

X

Interior equipment F

Bed coverlet

O

Bed with slatted frame and spring mattress

X

Blanket

O

Comfort table in U lounge

O

Decorative curtains

X

Decorative pillows (4 pcs) 42x42 cm

O

Floor carpets

O

Foldable bunk bunk bed above parents bed

/

Headrest at sitting group

X

Kitchen window lining with LED lightening

X

Liftable headrest on parents bed

X

Overall sleeping places

7 ( + 1 op.)

Sitting group with Kaltschaum

X

Sleeping area, bunk beds (cm)

179x68, 179x73 (+ 171x61 op.)

Sleeping area, central berths (cm)

200x136, 190x40

Sleeping area, front berths (cm)

224x145

Sleeping area, rear berths (cm)

/

Table with wooden profile and telescopic leg

X

Kitchen equipment G

3-flame gas cooker with electric ignition, glass cover and stainless steel sink

X

Drainer

O

Extractor fan

X

Kitchen taps (cold & hot water)

X

Microwave oven

O

Microwave oven preinstallation

X

Oven

X

Refrigerator

167 L

Sink cover / chopping board

O

Bathroom equipment H

Adria Ergobath type

A

Bathroom taps (washing & showering)

-

Foldable washbasin

X

Separate shower cabin with solid door

X

Separate shower faucet

X

Shower curtain

X

Shower tray

X

WC chemical, fixed, passive ventilated

-

WC chemical, turnable, passive ventilated

X

Wash-bowl

-

Washbasin in bedroom

-

Water installations I

Central waste water outlet

X

External inlet water connection to water facilities

X

Fresh water tank with external inlet (L)

50 L

Integrated waste water tank

O

Waste water tank (L)

O

Water level regulator 20l/50l

O

Electricity J

12V socket and TV aerial connector with coaxial cable

X

13-pin socket Jaeger

X

Additional spot lights in sitting area

X

Ambient LED lights below cupboards

X

Ambient LED lights on corner elements

X

Ambient LED lights over cupboards

X

Ambiental LED light at the bottom of kitchen unit

X

Awning LED light

X

Battery charger with battery box and external multifunctional outlet

X

Ceiling LED lights

X

Central lighting control panel

X

Control panel

X

LED rear exterior lights

X

Light in luggage compartment

X

Main fit switch

X

Main light switch at entrance door

X

Power sockets

X

Preinstallation for roof clima device

X

Signal D+ Preinstalations

X

Spot LED lights

X

USB switch

2x

Winter switch

X

Heating/air conditioning K

Hot-water floor heating system Alde

X

Hot-water heating system Alde Compact 3000

X

Preinstallation for air condition

X

Smart control Alde

O

Gas L

Gas bottle compartment 2 x 11 kg

X

Gas bottle holder

X

Gas regulation valve

X

Audio/video M

Bluetooth transmitter

O

Loudspeakers with preinstallation for bluetooth transmitter

X

TV holder

X

663 PT

Textiles

Brown Betty
Leather Fumo
Pommery

663 PT

Total length (including towing bar) (mm) B12

8680 B12

Total width (mm) B15

2460 B15

Mass in running order (kg) B5

1742 B5

Max. No. of berths O1b

6 O1b

Technical data

Dimensions and weights B

Awning perimeter dimensions (body/chassis) (cm)

1127/682

Body length (mm)

7251

Ex-Works weight ( kg )

1637

Floor, wall and roof insulation thickness (mm)

38/29/29

Floor, wall and roof total thickness (mm)

47/33/32,8

Internal height (mm)

1950

Internal length (mm)

6632

Internal width (mm)

2310

Mass in running order (MRO) ( kg )

1742

Max loading weight (kg)

258

Max. technically permissible laden mass (MTPLM) / optional (kg)

2000

Total height (mm)

2600

Total length (including towing bar) (mm)

8680

Total width (mm)

2460

Chassis equipment C

AL-KO automatic adjustment

available with ATC

ATC Trailer Control

O

Alloy wheels

O

Chassis type

AL-KO

Coupling device AK

200 V AK 300

Coupling device AKS

O

Delta axle

X

Drawbar cover

X

Mud protection

O

Number of axles

1

Reinforced supporting legs

X

Shock absorbers

X

Spare wheel with holder

O

Steel wheels

X

Third wheel with the real tyre

O

Tyres size

215R14C108

Wheel box insulation

X

Wheel cover insert

X

Wheel trims

X

Body E

Adria windows - darker

X

Black-out roller blinds with flyscreen on all windows

X

Bodywork in polyester

X

Decorative roof luggage rack

X

Double gazed front windscreen

X

Entrance door 1-part with window

X

Exterior graphic design labels

X

Floor insulation Styrofoam

X

Flyscreen whole door

O

Front and rear wall lining in thermoformed ABS

X

Gas bottle locker

X

I-shape exterior design

X

Integrated aluminium tent profiles

X

Luggage door - left (light dimensions) (cm)

25x105 ( not ASupremeP3)

Luggage door - right (light dimensions) (cm)

34x24

Movable entrance step

X

Opening windows all

X

Panoramic window for caravans

-

Roof light Midi Heki 70x50 cm

X

Roof light Mini Heki S 40x40 cm

X

Side wall skirtings in aluminium

X

Side walls in polyester

X

Third break light

X

Interior equipment F

Bed coverlet

O

Bed with slatted frame and spring mattress

X

Blanket

O

Decorative curtains

X

Decorative pillows (4 pcs) 42x42 cm

O

Floor carpets

O

Foldable bunk bunk bed above parents bed

/

Headrest at sitting group

X

Kitchen window lining with LED lightening

X

Liftable headrest on parents bed

X

Overall sleeping places

6 (+1 op.)

Sitting group with Kaltschaum

X

Sleeping area, bunk beds (cm)

179x68, 179x73 (+ 171x61 op.)

Sleeping area, central berths (cm)

217x110

Sleeping area, front berths (cm)

200x152

Sleeping area, rear berths (cm)

/

Table with wooden profile and telescopic leg

X

Kitchen equipment G

3-flame gas cooker with electric ignition, glass cover and stainless steel sink

X

Drainer

O

Extractor fan

X

Kitchen taps (cold & hot water)

X

Microwave oven

O

Microwave oven preinstallation

X

Oven

X

Refrigerator

167 L

Sink cover / chopping board

O

Bathroom equipment H

Adria Ergobath type

B

Bathroom taps (washing & showering)

-

Foldable washbasin

X

Separate shower cabin with solid door

X

Separate shower faucet

X

Shower curtain

-

Shower tray

X

WC chemical, fixed, passive ventilated

X

WC chemical, turnable, passive ventilated

-

Wash-bowl

-

Washbasin in bedroom

-

Water installations I

Central waste water outlet

X

External inlet water connection to water facilities

X

Fresh water tank with external inlet (L)

50 L

Integrated waste water tank

O

Waste water tank (L)

O

Water level regulator 20l/50l

O

Electricity J

12V socket and TV aerial connector with coaxial cable

X

13-pin socket Jaeger

X

Additional spot lights in sitting area

X

Ambient LED lights below cupboards

X

Ambient LED lights over cupboards

X

Ambiental LED light at the bottom of kitchen unit

X

Awning LED light

X

Battery charger with battery box and external multifunctional outlet

X

Ceiling LED lights

X

Central lighting control panel

X

Control panel

X

LED rear exterior lights

X

Light in luggage compartment

X

Main fit switch

X

Main light switch at entrance door

X

Power sockets

X

Preinstallation for roof clima device

X

Signal D+ Preinstalations

X

Spot LED lights

X

USB switch

2x

Winter switch

X

Heating/air conditioning K

Hot-water floor heating system Alde

X

Hot-water heating system Alde Compact 3000

X

Preinstallation for air condition

X

Smart control Alde

O

Gas L

Gas bottle compartment 2 x 11 kg

X

Gas bottle holder

X

Gas regulation valve

X

Audio/video M

Bluetooth transmitter

O

Loudspeakers with preinstallation for bluetooth transmitter

X

TV holder

X

663 HT

Textiles

Brown Betty
Leather Fumo
Pommery

663 HT

Total length (including towing bar) (mm) B12

8690 B12

Total width (mm) B15

2460 B15

Mass in running order (kg) B5

1740 B5

Max. No. of berths O1b

5 O1b

Technical data

Dimensions and weights B

Awning perimeter dimensions (body/chassis) (cm)

1127/682

Body length (mm)

7281

Ex-Works weight ( kg )

1650

Floor, wall and roof insulation thickness (mm)

38/29/29

Floor, wall and roof total thickness (mm)

47/33/32,8

Internal height (mm)

1950

Internal length (mm)

6632

Internal width (mm)

2310

Mass in running order (MRO) ( kg )

1740

Max loading weight (kg)

260

Max. technically permissible laden mass (MTPLM) / optional (kg)

2000

Total height (mm)

2600

Total length (including towing bar) (mm)

8690

Total width (mm)

2460

Chassis equipment C

AL-KO automatic adjustment

available with ATC

ATC Trailer Control

O

Alloy wheels

O

Chassis type

AL-KO

Coupling device AK

200 V AK 300

Coupling device AKS

O

Delta axle

X

Drawbar cover

X

Mud protection

O

Number of axles

1

Reinforced supporting legs

X

Shock absorbers

X

Spare wheel with holder

O

Steel wheels

X

Third wheel with the real tyre

O

Tyres size

215R14C108

Wheel box insulation

X

Wheel cover insert

X

Wheel trims

X

Body E

Adria windows - darker

X

Black-out roller blinds with flyscreen on all windows

X

Bodywork in polyester

X

Decorative roof luggage rack

X

Double gazed front windscreen

X

Entrance door 1-part with window

X

Exterior graphic design labels

X

Floor insulation Styrofoam

X

Flyscreen whole door

O

Front and rear wall lining in thermoformed ABS

X

Gas bottle locker

X

I-shape exterior design

X

Integrated aluminium tent profiles

X

Luggage door - left (light dimensions) (cm)

28x72, 72x27

Luggage door - right (light dimensions) (cm)

/

Movable entrance step

X

Opening windows all

X

Panoramic window for caravans

X

Roof light Midi Heki 70x50 cm

X

Roof light Mini Heki S 40x40 cm

X

Side wall skirtings in aluminium

X

Side walls in polyester

X

Third break light

X

Interior equipment F

Bed coverlet

O

Bed with slatted frame and spring mattress

X

Blanket

O

Decorative curtains

X

Decorative pillows (4 pcs) 42x42 cm

O

Floor carpets

O

Foldable bunk bunk bed above parents bed

/

Headrest at sitting group

X

Kitchen window lining with LED lightening

X

Liftable headrest on parents bed

X

Overall sleeping places

5

Sitting group with Kaltschaum

X

Sleeping area, bunk beds (cm)

/

Sleeping area, central berths (cm)

217x110, 180x65

Sleeping area, front berths (cm)

/

Sleeping area, rear berths (cm)

190x150

Sliding bed

X

Table with wooden profile and telescopic leg

X

Kitchen equipment G

3-flame gas cooker with electric ignition, glass cover and stainless steel sink

X

Drainer

O

Extractor fan

-

Kitchen taps (cold & hot water)

X

Microwave oven

O

Microwave oven preinstallation

X

Oven

X

Refrigerator

167 L

Sink cover / chopping board

O

Bathroom equipment H

Adria Ergobath type

C

Bathroom taps (washing & showering)

-

Foldable washbasin

X

Separate shower cabin with solid door

X

Separate shower faucet

X

Shower curtain

-

Shower tray

X

WC chemical, fixed, passive ventilated

-

WC chemical, turnable, passive ventilated

X

Wash-bowl

-

Washbasin in bedroom

-

Water installations I

Central waste water outlet

X

External inlet water connection to water facilities

X

Fresh water tank with external inlet (L)

50 L

Integrated waste water tank

O

Waste water tank (L)

O

Water level regulator 20l/50l

O

Electricity J

12V socket and TV aerial connector with coaxial cable

X

13-pin socket Jaeger

X

Additional spot lights in sitting area

X

Ambient LED lights below cupboards

X

Ambient LED lights on corner elements

X

Ambient LED lights over cupboards

X

Ambiental LED light at the bottom of kitchen unit

X

Awning LED light

X

Battery charger with battery box and external multifunctional outlet

X

Ceiling LED lights

X

Central lighting control panel

X

Control panel

X

LED rear exterior lights

X

Light in luggage compartment

X

Main fit switch

X

Main light switch at entrance door

X

Power sockets

X

Preinstallation for roof clima device

X

Signal D+ Preinstalations

X

Spot LED lights

X

USB switch

2x

Winter switch

X

Heating/air conditioning K

Hot-water floor heating system Alde

X

Hot-water heating system Alde Compact 3000

X

Preinstallation for air condition

X

Smart control Alde

O

Gas L

Gas bottle compartment 2 x 11 kg

X

Gas bottle holder

X

Gas regulation valve

X

Audio/video M

Bluetooth transmitter

O

Loudspeakers with preinstallation for bluetooth transmitter

X

TV holder

X

753 UP

Textiles

Brown Betty
Leather Fumo
Pommery

753 UP

Total length (including towing bar) (mm) B12

9560 B12

Total width (mm) B15

2460 B15

Mass in running order (kg) B5

1986 B5

Max. No. of berths O1b

6 O1b

Technical data

Dimensions and weights B

Awning perimeter dimensions (body/chassis) (cm)

1211/766

Body length (mm)

8110

Ex-Works weight ( kg )

1880

Floor, wall and roof insulation thickness (mm)

38/29/29

Floor, wall and roof total thickness (mm)

47/33/32,8

Internal height (mm)

1950

Internal length (mm)

7472

Internal width (mm)

2310

Mass in running order (MRO) ( kg )

1986

Max loading weight (kg)

514

Max. technically permissible laden mass (MTPLM) / optional (kg)

2500

Total height (mm)

2600

Total length (including towing bar) (mm)

9560

Total width (mm)

2460

Chassis equipment C

Alloy wheels

O

Chassis type

BPW

Coupling device AK

200 V AK 300

Coupling device AKS

O

Delta axle

X

Drawbar cover

X

Mud protection

O

Number of axles

2

Reinforced supporting legs

X

Shock absorbers

X

Spare wheel with holder

O

Steel wheels

X

Third wheel with the real tyre

O

Tyres size

185 R14 C 102 (2500)

Wheel box insulation

X

Wheel cover insert

X

Wheel trims

X

iDC BWP Stability system

O

Body E

Adria windows - darker

X

Black-out roller blinds with flyscreen on all windows

X

Bodywork in polyester

X

Decorative roof luggage rack

X

Double gazed front windscreen

X

Entrance door 1-part with window

X

Exterior graphic design labels

X

Floor insulation Styrofoam

X

Flyscreen whole door

O

Front and rear wall lining in thermoformed ABS

X

Gas bottle locker

X

I-shape exterior design

X

Integrated aluminium tent profiles

X

Luggage door - left (light dimensions) (cm)

27x105, 34x24

Luggage door - right (light dimensions) (cm)

34x24

Movable entrance step

X

Opening windows all

X

Panoramic window for caravans

X

Roof light Midi Heki 70x50 cm

X

Roof light Mini Heki S 40x40 cm

X

Side wall skirtings in aluminium

X

Side walls in polyester

X

Third break light

X

Interior equipment F

Bed coverlet

O

Bed with slatted frame and spring mattress

X

Blanket

O

Comfort table in U lounge

O

Decorative curtains

X

Decorative pillows (4 pcs) 42x42 cm

O

Floor carpets

O

Foldable bunk bunk bed above parents bed

190x65

Headrest at sitting group

X

Kitchen window lining with LED lightening

X

Liftable headrest on parents bed

X

Overall sleeping places

6

Sitting group with Kaltschaum

X

Sleeping area, bunk beds (cm)

/

Sleeping area, central berths (cm)

195x85

Sleeping area, front berths (cm)

224x145

Sleeping area, rear berths (cm)

200x150

Table with wooden profile and telescopic leg

X

Kitchen equipment G

3-flame gas cooker with electric ignition, glass cover and stainless steel sink

X

Drainer

O

Extractor fan

X

Kitchen taps (cold & hot water)

X

Microwave oven

O

Microwave oven preinstallation

X

Oven

X

Refrigerator

167 L

Sink cover / chopping board

O

Bathroom equipment H

Adria Ergobath type

C

Bathroom taps (washing & showering)

-

Foldable washbasin

-

Separate shower cabin with solid door

X

Separate shower faucet

X

Shower curtain

-

Shower tray

X

WC chemical, fixed, passive ventilated

-

WC chemical, turnable, passive ventilated

X

Wash-bowl

-

Washbasin in bedroom

-

Water installations I

Central waste water outlet

X

External inlet water connection to water facilities

X

Fresh water tank with external inlet (L)

50 L

Integrated waste water tank

O

Waste water tank (L)

O

Water level regulator 20l/50l

O

Electricity J

12V socket and TV aerial connector with coaxial cable

X

13-pin socket Jaeger

X

Additional spot lights in sitting area

X

Ambient LED lights below cupboards

X

Ambient LED lights on corner elements

X

Ambient LED lights over cupboards

X

Ambiental LED light at the bottom of kitchen unit

X

Awning LED light

X

Battery charger with battery box and external multifunctional outlet

X

Ceiling LED lights

X

Central lighting control panel

X

Control panel

X

LED rear exterior lights

X

Light in luggage compartment

X

Main fit switch

X

Main light switch at entrance door

X

Power sockets

X

Preinstallation for roof clima device

X

Signal D+ Preinstalations

X

Spot LED lights

X

USB switch

2x

Winter switch

X

Heating/air conditioning K

Hot-water floor heating system Alde

X

Hot-water heating system Alde Compact 3000

X

Preinstallation for air condition

X

Smart control Alde

O

Gas L

Gas bottle compartment 2 x 11 kg

X

Gas bottle holder

X

Gas regulation valve

X

Audio/video M

Bluetooth transmitter

O

Loudspeakers with preinstallation for bluetooth transmitter

X

TV holder

X

753 HT

Textiles

Brown Betty
Leather Fumo
Pommery

753 HT

Total length (including towing bar) (mm) B12

9590 B12

Total width (mm) B15

2460 B15

Mass in running order (kg) B5

1896 B5

Max. No. of berths O1b

5 O1b

Technical data

Dimensions and weights B

Awning perimeter dimensions (body/chassis) (cm)

1211/766

Body length (mm)

8091

Ex-Works weight ( kg )

1790

Floor, wall and roof insulation thickness (mm)

38/29/29

Floor, wall and roof total thickness (mm)

47/33/32,8

Internal height (mm)

1950

Internal length (mm)

7472

Internal width (mm)

2310

Mass in running order (MRO) ( kg )

1896

Max loading weight (kg)

604

Max. technically permissible laden mass (MTPLM) / optional (kg)

2500

Total height (mm)

2600

Total length (including towing bar) (mm)

9590

Total width (mm)

2460

Chassis equipment C

Alloy wheels

O

Chassis type

BPW

Coupling device AK

251SAK300/2500kg

Coupling device AKS

O

Delta axle

X

Drawbar cover

X

Mud protection

O

Number of axles

2

Reinforced supporting legs

X

Shock absorbers

X

Spare wheel with holder

O

Steel wheels

X

Third wheel with the real tyre

O

Tyres size

185 R14 C 102 (2500 )

Wheel box insulation

X

Wheel cover insert

X

Wheel trims

X

iDC BWP Stability system

O

Body E

Adria windows - darker

X

Black-out roller blinds with flyscreen on all windows

X

Bodywork in polyester

X

Decorative roof luggage rack

X

Double gazed front windscreen

X

Entrance door 1-part with window

X

Exterior graphic design labels

X

Floor insulation Styrofoam

X

Flyscreen whole door

O

Front and rear wall lining in thermoformed ABS

X

Gas bottle locker

X

I-shape exterior design

X

Integrated aluminium tent profiles

X

Luggage door - left (light dimensions) (cm)

72x27

Luggage door - right (light dimensions) (cm)

27x105

Movable entrance step

X

Opening windows all

X

Panoramic window for caravans

X

Roof light Midi Heki 70x50 cm

X

Roof light Mini Heki S 40x40 cm

X

Side wall skirtings in aluminium

X

Side walls in polyester

X

Third break light

X

Interior equipment F

Bed coverlet

O

Bed with slatted frame and spring mattress

X

Blanket

O

Decorative curtains

X

Decorative pillows (4 pcs) 42x42 cm

O

Floor carpets

O

Foldable bunk bunk bed above parents bed

/

Headrest at sitting group

X

Kitchen window lining with LED lightening

X

Liftable headrest on parents bed

X

Overall sleeping places

5

Sitting group with Kaltschaum

X

Sleeping area, bunk beds (cm)

/

Sleeping area, central berths (cm)

217x110

Sleeping area, front berths (cm)

/

Sleeping area, rear berths (cm)

200x80, 193x80

Table with wooden profile and telescopic leg

X

Kitchen equipment G

3-flame gas cooker with electric ignition, glass cover and stainless steel sink

X

Drainer

O

Extractor fan

-

Kitchen taps (cold & hot water)

X

Microwave oven

O

Microwave oven preinstallation

X

Oven

X

Refrigerator

167 L

Sink cover / chopping board

O

Bathroom equipment H

Adria Ergobath type

C

Bathroom taps (washing & showering)

-

Foldable washbasin

-

Separate shower cabin with solid door

X

Separate shower faucet

X

Shower curtain

-

Shower tray

X

WC chemical, fixed, passive ventilated

-

WC chemical, turnable, passive ventilated

X

Wash-bowl

X

Washbasin in bedroom

-

Water installations I

Central waste water outlet

X

External inlet water connection to water facilities

X

Fresh water tank with external inlet (L)

50 L

Integrated waste water tank

O

Waste water tank (L)

O

Water level regulator 20l/50l

O

Electricity J

12V socket and TV aerial connector with coaxial cable

X

13-pin socket Jaeger

X

Additional spot lights in sitting area

X

Ambient LED lights below cupboards

X

Ambient LED lights on corner elements

X

Ambient LED lights over cupboards

X

Ambiental LED light at the bottom of kitchen unit

X

Awning LED light

X

Battery charger with battery box and external multifunctional outlet

X

Ceiling LED lights

X

Central lighting control panel

X

Control panel

X

LED rear exterior lights

X

Light in luggage compartment

X

Main fit switch

X

Main light switch at entrance door

X

Power sockets

X

Preinstallation for roof clima device

X

Signal D+ Preinstalations

X

Spot LED lights

X

USB switch

2x

Winter switch

X

Heating/air conditioning K

Hot-water floor heating system Alde

X

Hot-water heating system Alde Compact 3000

X

Preinstallation for air condition

X

Smart control Alde

O

Gas L

Gas bottle compartment 2 x 11 kg

X

Gas bottle holder

X

Gas regulation valve

X

Audio/video M

Bluetooth transmitter

O

Loudspeakers with preinstallation for bluetooth transmitter

X

TV holder

X

903 HT

Textiles

Brown Betty
Leather Fumo
Pommery

903 HT

Total length (including towing bar) (mm) B12

11030 B12

Total width (mm) B15

2460 B15

Mass in running order (kg) B5

2326 B5

Max. No. of berths O1b

9 O1b

Technical data

Dimensions and weights B

Awning perimeter dimensions (body/chassis) (cm)

1356/911

Body length (mm)

9533

Ex-Works weight ( kg )

2220

Floor, wall and roof insulation thickness (mm)

34/29/29

Floor, wall and roof total thickness (mm)

47/33/32,8

Internal height (mm)

1950

Internal length (mm)

8920

Internal width (mm)

2310

Mass in running order (MRO) ( kg )

2326

Max loading weight (kg)

474

Max. technically permissible laden mass (MTPLM) / optional (kg)

2800

Total height (mm)

2600

Total length (including towing bar) (mm)

11030

Total width (mm)

2460

Chassis equipment C

Alloy wheels

O

Chassis type

BPW

Coupling device AK

251SAK300/2500kg

Coupling device AKS

O

Delta axle

X

Drawbar cover

X

Mud protection

O

Number of axles

2

Reinforced supporting legs

X

Shock absorbers

X

Spare wheel with holder

O

Steel wheels

X

Third wheel with the real tyre

O

Tyres size

185 R14 C 102 (2500)

Wheel box insulation

X

Wheel cover insert

X

Wheel trims

X

iDC BWP Stability system

O

Body E

Adria windows - darker

X

Black-out roller blinds with flyscreen on all windows

X

Bodywork in polyester

X

Decorative roof luggage rack

X

Double gazed front windscreen

X

Entrance door 1-part with window

X

Exterior graphic design labels

X

Floor insulation Styrofoam

X

Flyscreen whole door

O

Front and rear wall lining in thermoformed ABS

X

Gas bottle locker

X

I-shape exterior design

X

Integrated aluminium tent profiles

X

Luggage door - left (light dimensions) (cm)

72x27

Luggage door - right (light dimensions) (cm)

27x105

Movable entrance step

X

Opening windows all

X

Panoramic window for caravans

X

Roof light Midi Heki 70x50 cm

X

Roof light Mini Heki S 40x40 cm

X

Side wall skirtings in aluminium

X

Side walls in polyester

X

Third break light

X

Interior equipment F

Bed coverlet

O

Bed with slatted frame and spring mattress

X

Blanket

O

Decorative curtains

X

Decorative pillows (4 pcs) 42x42 cm

O

Floor carpets

O

Foldable bunk bunk bed above parents bed

190x65

Footstool

O

Headrest at sitting group

X

Kitchen window lining with LED lightening

X

Liftable headrest on parents bed

X

Overall sleeping places

9

Sitting group with Kaltschaum

X

Sleeping area, bunk beds (cm)

2x190x72

Sleeping area, central berths (cm)

195x85

Sleeping area, front berths (cm)

200x117, 180x65

Sleeping area, rear berths (cm)

190x150

Sliding bed

X

Table with wooden profile and telescopic leg

X

Kitchen equipment G

3-flame gas cooker with electric ignition, glass cover and stainless steel sink

X

Drainer

O

Extractor fan

-

Kitchen taps (cold & hot water)

X

Microwave oven

O

Microwave oven preinstallation

X

Oven

X

Refrigerator

167 L

Sink cover / chopping board

O

Bathroom equipment H

Adria Ergobath type

C

Bathroom taps (washing & showering)

-

Foldable washbasin

-

Separate shower cabin with solid door

X

Separate shower faucet

X

Shower tray

X

WC chemical, fixed, passive ventilated

-

WC chemical, turnable, passive ventilated

X

Water installations I

Central waste water outlet

X

External inlet water connection to water facilities

X

Fresh water tank with external inlet (L)

50 L

Integrated waste water tank

O

Waste water tank (L)

O

Water level regulator 20l/50l

O

Electricity J

12V socket and TV aerial connector with coaxial cable

X

13-pin socket Jaeger

X

Additional spot lights in sitting area

X

Ambient LED lights below cupboards

X

Ambient LED lights on corner elements

X

Ambient LED lights over cupboards

X

Ambiental LED light at the bottom of kitchen unit

X

Awning LED light

X

Battery charger with battery box and external multifunctional outlet

X

Ceiling LED lights

X

Central lighting control panel

X

Control panel

X

LED rear exterior lights

X

Light in luggage compartment

X

Main fit switch

X

Main light switch at entrance door

X

Power sockets

X

Preinstallation for roof clima device

X

Signal D+ Preinstalations

X

Spot LED lights

X

USB switch

2x

Winter switch

X

Heating/air conditioning K

Hot-water floor heating system Alde

X

Hot-water heating system Alde Compact 3000

X

Preinstallation for air condition

X

Smart control Alde

O

Gas L

Gas bottle compartment 2 x 11 kg

X

Gas bottle holder

X

Gas regulation valve

X

Audio/video M

Bluetooth transmitter

O

Loudspeakers with preinstallation for bluetooth transmitter

X

TV holder

X

2. New in 2017 & key features

  • Adria i-shaped exterior design with new graphics.
  • Adria Comprex body construction.
  • Floor with additional 4mm insulation.
  • Panoramic window on most layouts.
  • Seitz DeLuxe windows with integrated mosquito net and blinds.
  • AL-KO chassis or BPW chassis (on double axle Alpina).
  • Elegant new interior design and choice of textiles.
  • Comfortable beds and accommodation for up-to 9 people dependent on layout, with deep mattresses on parents beds.
  • Extra-large and flexible lounge seating group with addition of comfortable and elegant headrests.
  • Adria Smart kitchen with gas burners, sink, worktop, oven and large fridge.
  • Stylish Ergo bathroom with quality bathroom equipment.
  • Fully integrated Alde heating with optional Alde Smart control.
  • Bluetooth with USB ports and loud-speakers.
  • Optimized storage including unique concave deep design overhead cupboards.
  • Plus individual options available.

3. Textiles

Brown Betty
Leather Fumo
Pommery

Exterior features

Picture for illustration purposes only. Details may vary.

The Alpina, with 'i-shaped' exterior, new graphics and contemporary and elegant interior, represents the ultimate caravan for all year round adventures. Inside there is more space and thanks to the unique concave cupboard design, more of a loft-style apartment feeling and the benefits of fully integrated Alde heating.


Unique i-shaped exterior design with integrated features.

Exterior LED lights controlled from new light panel.

Panoramic window on many layouts.

Seitz DeLuxe windows with integrated mosquito net and blinds.

AL-KO chassis or BPW chassis (model dependent).

Adria Comprex body construction, for a more solid body and with better insulation.

Interior features

Picture for illustration purposes only. Details may vary.

The new benchmark for all-seasons caravans, with uncompromised space, contemporary interior designs and new layouts. The elegant interior, with a choice of textiles, offers larger living space, a choice of sleeping solutions, Adria's Smart kitchen and Ergo bathroom.


Extra-large and multi-functional living area.

Hotel-style Ergo bathroom in hotel style with quality fittings.

Spacious, loft-style and elegant interior.

Smart kitchen with everything in the right place.

Optimized storage throughout, including unique concave design deep cupboards.

Fully integrated Alde heating with Smart Control option.



Alpina benefits from Adria's 'Comprex' construction which combines the torsional strength of wood, the durability of polyurethane and the moisture-stopping properties of polyester.

Interior features
